FAQ

 A fully automatic digital gabion production line (in sheet form).

Yes. The machine can be designed for a specific mesh size within the range of 50x70 mm to 176x200 mm, as per customer request.

pls refer the parameter form in our proposal and make sure the machine produce right wire diameter

Because of feeding wire from pay off is finished or wire broken ,the hole will appear in the net.

We could cut one short wire and netting the hole part by hand.

use butt welding machine ,or knot two wire by hand.

1. According to the layout diagram fixing the equipment.

2. Prearrange the payoff frames in concordance with the pay off drawing.

3. Connect to the Main switch which suite for total power 30KW. We suggest to use 18mm2 copper cable

4. Enough power cord from Main switch to Electric Control Box.

5. One set of 0.8MPA,0.6m3/MIN air compressor.

6. 1000KGS of 2.7mm wire , 500KGS of 3.4mm wire.

7. 200KGS lubricant.

One forklift, one crane (for loading and unloading, move gabion machine), complete set of tools, include big wire clipper.

We offer gabion machine with 380V three phases , 60HZ, we could change the current to 220V three phased or 440V three phased etc (change different current will have extra cost ).

Total 3 workers , one worker for main machine (check the spiral coiled wire in sleeve, and wire from pay off), one worker for wire spiral coiling machine, one workers for winding machine.

Min. size is 3200mm*1500mm(L/W), customer could send his factory layout we could design and make each machine’s right position

Usually we put around 200KGS wire in each pay off.

adjust two wheels At the both side of the machine.

Enwind on the tension roller make the wire straight .before the feeding wire though into main machine from pay off.

Max. 30meters

By hand. Usually our workers push the end of the roll net in winding bar. And the roll net can be easily take out.

One rolling net Max.weight is 300KGS.

it depends on the wire diameter, usually 800-1200meters for one piece spiral coiled wire.

Yes, it is used for sharpening the wire, then wire could pass through wire drawing mold.

Descaling is needed before drawing; it is used to remove rust and oxide on surface of wire.

Surely machine can draw different size of wire if you change drawing moulds, but diameter of wire must be within production range of machine.

Changing wire drawing mold is not complicated.

one piece of wire drawing mold min. for drawing 2 tons of wire.

2kg powder for drawing 1 ton of wire.

Mesh size: 80 x 100 mm.

Width: 4700 mm.

USD 94,260.00.

It includes 4 machines: Hexagonal wire netting machine, Wire tension machine, Wire spiral coiling machine, and Net winding machine. The total package price is USD 41,800.00.

Net straightening & cutting machine (USD 14,360.00), Gabion mesh conveying platform (USD 6,400.00), Wire straightening and cutting machine (USD 1,700.00), Net side bordering machine (USD 14,900.00), Double cylinder packing machine (USD 15,100.00).

Big gear made of casting steel with 4-5 year life; half gears are quenched for increased hardness; uses steel screws for critical parts; uses real copper for copper gears/sleeves/cams; main frame is 14mm thick; uses imported bearings; has an auto lubrication system and real copper bushes.

Max. netting width: 4700mm. Max. weaving wire diameter: 3.2mm. Max. bordering wire diameter: 4.0mm. Power: 30 kW. Manufacturing speed: 195 meters/hour. Exterior size: 8.2m (L) x 1.4m (W) x 2.4m (H). Weight: 16 Tons.

It is suitable for low carbon steel wire, galvanized wire (2.0mm–4.0mm range), and PVC coated galvanized wire (≤5.0mm).

 12 months after commissioning or 18 months after shipment, whichever comes first (excluding wear parts).

40% by T/T in advance as down payment, 60% by T/T before shipment.

Within 50 days after receipt of the down payment.

Provision of operation & maintenance manuals and parts documentation; installation and commissioning; training for factory operators and technicians; an installation/commissioning report.

1 technician and 1 interpreter will be provided for up to 15 working days for installation, commissioning, and training. The customer covers their travel, accommodation, meals, transportation, insurance, and taxes, plus a working fee of USD 120.00/day/person.

Yes, the document shows performance/references in multiple countries including France, Malaysia, Poland, Russia, Nepal, Thailand, etc

Yes, a list is provided including items like half gear dies, braking straps, hose tubes, electrical valves, etc., with quantities.

Yes, the document includes a step-by-step "Installation Process" section with diagrams showing how to assemble, connect, and fill the gabion units.

Yes, 1 technician and 1 interpreter will be assigned to coordinate installation, commissioning and training, for around 7 working days, your side will supply the air return tickets, food, accommodation, transportation, communication, insurance, tax (if have) for the technician and the interpreter.

USD80.00/day/person working fee will be paid to them.

It needs at least 7 days to train. You can dispatch your worker to our factory or we dispatch our technician to your factory to train.

The machines have the same warranty if working in two shifts.

12 months after commissioning or 18months after shipment. Whichever first is in valid. (It is excluding wear parts. Shipping cost for parts to be replaced during warranty period has to be borne by the customer.)

We pack the machines by wooden cases usually.

There is no specific temperature required; machines can work from -10℃ to 40℃.

We can help you send some raw material with machines; the price will be around US$900.00/ton. But we suggest you purchase the wire from Ukraine or Russia, theirs price is lower than China.

It is around 2 pairs each month if the machine works 8h/day.

Changing the nail mould and adjusting the wire feeding length. It will take around 15 minutes.

No, each Model of machine can produce the size of nail in a certain range, you can refer the Quotation.

The machines can be used continuously 24hours a day, and they need maintenance one or two times every month.

The rate of production waste is less than 1%.

The power supply is 380V; 3-Phase, 50Hz, but we can design the power supply of machine according to your state grid.

Heating Element is 0Cr25Al5 resistance tape, it is about 60~70kg per set of furnace.

Heating methods are different.

We have Electric Annealing Furnace, LPG Annealing Furnace, Natural Gas Annealing Furnace.

It is used to anneal wire after being drawn, which makes wire softer.

we will send you operation manual of machine after you place order and before you get the machine.

Please provide us layout of your workshop and quantity of machines, then we will provide you layout of workshop with all machines.

Machine normally is covered by plastic film.

2 workers for one wire drawing line.

Please let us know which machine and quantity of machine you plan to buy, and then we will calculate packing volume and sea freight to XXX port accordingly.

Yes.

Our machine normally is 380V, 3P, 50Hz, but it could be as your requirement.

Our machine is with different power according to different requirement for drawn wire, detailed please refer to our quotation.

Yes, it is auxiliary equipment of wire drawing production line, which is used to weld the wire if it is broken during being drawn.

If foundation and everything is prepared, time of installation and trial running is about 10 working days. Then it can be put into usage.

Delivery time is subject to machine model and quantity of machine you plan to purchase. Normally it is about 60 days after receipt of your down payment.

40% by T/T in advance as down payment, and 60% by Irrevocable Letter of Credit (L/C) at sight.

1 technician and 1 interpreter are provided for up to 7 working days for installation, commissioning, and training. The buyer covers their travel, accommodation, meals, transportation, insurance, and taxes, plus a working fee of USD 120.00/day/person.

The supplier offers two main types: Single Wire Chain Link Fence Machines and Double Wire Chain Link Fence Machines, available in netting widths of 2m, 3m, and 4m.

The Single Wire machine uses 1 input wire with a capacity of 40-120 m²/h, while the Double Wire machine uses 2 input wires with a higher capacity of 80-260 m²/h. The Double Wire machine is more powerful and has a higher output.

Single Wire: USD 9,450.00 (2m) to USD 10,250.00 (4m).

Double Wire: USD 14,350.00 (2m) to USD 15,300.00 (4m).

Yes. One machine can produce different mesh sizes by changing the mold. One set of mold is provided free of charge; additional molds cost USD 35.00-60.00/set.

The Net Compacting Machine compresses the finished mesh roll, making it thinner and reducing transportation costs. It is an optional accessory, adding an extra USD 1,100.00 - 1,400.00 to the price.

 The process involves: Pay-off feeding wire → Bending wire via pressure wheel & mold → Cooling/lubrication → Rotating mold to form mesh → Cutting wire to preset length → Weaving into mesh → Side locking (curving/twisting edges) → Rolling the finished mesh.

 Standard power supply is 380V/50Hz (customizable). The machines are suitable for galvanized wire, PVC-coated wire, and steel wire. Wire diameter ranges from 1.5-4.5mm for Single Wire and 1.8-4.5mm for Double Wire, depending on mesh size.

Both machine types can produce mesh sizes from 25x25mm to 100x100mm. (Note: Producing 25x25mm requires very uniform steel wire).

For a 2m wide machine, the layout should be at least 8m (L) x 8m (W) x 5m (H). For a 4m wide machine, it should be at least 10m (L) x 8m (W) x 5m (H).

One complete production line can be operated by two people

The machine includes an emergency stop remote controller, allowing workers to stop the machine remotely in case of an emergency.

The side edges can be finished as curved (bent) type or twisted type. You can choose to have both sides the same or one side curved and the other twisted.

The equipment is guaranteed for 12 months after commissioning or 15 months after shipping, whichever occurs first.

Delivery is effected within 35 days upon receipt of the down payment.

Yes, the document shows export references to countries including Nepal, El Salvador, and Canada from 2018 to 2024.

A lubricating/cooling system uses a liquid whose main ingredients are emulsion and water to cool and lubricate the mold during operation.

The line operates at a speed of 80-100 meters per minute.

The required space, including the wire pay-off and take-up areas, is 22 meters (L) x 3.5 meters (W).

The complete line is packed into one 20-foot General Purpose (GP) shipping container.

The main power cable required is 3*25mm² + 1. The standard power supply is 380V, 3-Phase, 50Hz. Customized voltage requirements are available at an extra cost.

The entire production line can be operated by just 1 person.

    *   Screw Diameter: 80mm

    *   Slenderness Ratio: 28:1

    *   Coating Thickness Range: 0.5 - 0.8 mm

    *   Suitable Wire Diameter: 1.0 - 5.0 mm

    *   Main Motor Power: 37 KW

    *   Heating Power: 20 KW (5 zones)

For a 2.25mm diameter wire, the capacity is approximately 1,520 kg per 8-hour shift.

The line includes a 6-meter long water cooling tank with a 220mm x 220mm cross-section.

 It pulls the wire through the coating and cooling process. It is equipped with a 5.5 KW motor, 4-speed hard gear transmission, and a Φ600mm hauling wheel.

It automatically winds the finished PVC-coated wire onto spools. It handles wire diameters from 0.8-5.0mm and is powered by a 5.5 KW motor.

The FOB China price for the complete PVC Coating Line is CNY 139,600.00.

 Yes, 3 sets of standard molds (for sizes 2.2/3.3mm, 2.7/3.8mm, and 3.5/4.6mm) are included with the main line.

Yes, extra mold sets are available at a price of CNY 230.00 per set.

The CIF price to Klang Port, Malaysia, including sea freight, is CNY 151,100.00.

40% by T/T in advance as a down payment, and the remaining 60% by T/T before shipment.

Delivery is within 45 days after receipt of the down payment.

Equipment is packed with plastic film for safety and then secured in wooden cases.

The warranty is valid for 12 months after commissioning or 18 months after shipment, whichever comes first. (Note: Wear parts are excluded, and the customer bears shipping costs for replacement parts during the warranty period).
