High Speed Nail Making Machine

Availability:
Quantity:

High speed nail making machine



High speed nail making machine with CE certificate


Machine introduce


High speed automatic nail making machine is applied to requirements for making nails with large batch, high precision and high production capacity. High speed automatic nail making machine is featured by outstanding safety performance, stable quality, high reliability, convenient use and maintenance. PLC control and equipped with full-range optically controlled wire disorder shutdown system.
.

Nail Length: 35-90mm
Nail Diameter:2.0-3.6mm

This machine adopts plunger type stricture so as to ensure the features such as highSpeed, low noise and less impact. Especially, it can make the high quality of nails.

Each nail making machine supply related nail mould, nail knife and punch pin ect spare parts



Main Technical Parameter

Technical Data

Parameters

CD-HS90

Nail Diameter

2.0-3.6mm

Nail Length

35-90mm

Speed

760pcs/min

Power

7.0kw

External Dimension

1850*1200*1150mm

Control Cabinet Dimension

400*600*800mm

Weight

2800kg



  750-H-3_03

750-H-3_05

800-制钉机-5.

750-H-3_06

750-H-3_07

750-H-3_08

800-制钉机-4.
