Three important devices in wire drawing machine equipment

In the drawing machine equipment, it is often necessary to equip many related devices to ensure that it can successfully complete the drawing task. Here, we will introduce three more important devices in the wire drawing machine equipment-winding head, cable arrangement and cable separation device. I hope that through this introduction, we can help you understand the device more deeply.

First, let's understand the characteristics and main functions of the lower winding head structure together. Normally, the entire head is made of aluminum alloy and stainless steel. And its structure is a centrifugal expansion block type. During the operation of the wire drawing machine, its head will maintain a high-speed rotation state. Therefore, the expansion block will support the winding drum under the action of centrifugal force, and the fiber is wound. On the surface of the bobbin. After the work is completed, the machine head stops rotating, the centrifugal force disappears, and the swelling block falls freely to perform the unloading operation.

So, what are the characteristics of the cable arrangement in the wire drawing machine? Normally, there are two types of operation: rotary motion and reciprocating motion. The former is realized by the spool motor through synchronous belt drive, while the latter is realized by the servo motor through the synchronous belt, rolling screw assembly and linear bearing drive.

Let's take a look at what is the cable traverse device. For the wire drawing machine equipment, the main function of the device is shown in two aspects, one is to move the cable arranging to the direction of the machine head at the beginning of winding, and the other is to extend with time during the winding process and The increase of the thickness of the cake can make the cable move to the right gradually, and ensure the same tension of the inner and outer layers of the cake.

The content described above is about the functions and characteristics of the three important devices in the wire drawing machine equipment. I believe that after the analysis of these contents, friends have a full understanding of this content, and I hope to provide you with some reference.
